IGS-NT Installation Guide
66
7.9. IM-NTC-BB
7.9.1. Schematics
DISPLAY
(1)
EXTENSION
MODULES
INTERCONTROLLER
& MONITORING
www.comap.cz
Order code:
IM-NTC-BB
MADE IN THE EU
Inteli
NT
BaseBox
Mains
L
H
L
H
2
2
MAINS (BUS-L) VOLTAGE
2
BUS (BUS-R) VOLTAGE
3x277 /480 V or 120 /207 V
2
MAX 0,74 A
7
MAINS (BUS-L) VOLTAGE CURRENT 01/05A
Left to right: Pull down Bias / 120Ω / Pull up Bias / 120Ω / 120Ω
Down: AI4 setting / AI3 setting / AI2 setting / AI1 setting
Current input 0-25mA
Voltage input 0-5V
Resistance input 0-2400 Ω
Boot jumper (upper one, rest of the jumpers is for internal use only)
Left to right: Pull up Bias / 120Ω / Pull down Bias
AOUT setting
Voltage 0-10VDC Current 0-20mA
