IGS-NT Installation Guide
138
20. Technical Data
20.1. Power supply
Controller
IS-Display
IG-Display
InteliVision
8
InteliVision
5
Voltage
supply
8-36V DC
8-36V DC
8-36V DC
8-36V DC
8-36V DC
Consumption
depends on
supply
voltage
0,4A at
8VDC
0,3A at
8VDC
0,4A at
8VDC
1A at 8VDC
0.7 A at
8VDC
0,15 A at
24VDC
0,1 A at
24VDC
0,14 A at
24VDC
0,35A at
24VDC
0.55 A at
24VDC
0,1A at
36VDC
0,09A at
30VDC
0,12A at
30VDC
0,25A at
36VDC
0.45 A at
36VDC
Battery
voltage
measurement
tolerance
2 % at 24V
RTC battery
life-cycle
10 year
HINT
When internal RTC battery becomes flat, controller function (e.g. Ready for stand by) does
not change until controller power supply is switched off. Some time before the battery is
completely exhausted, a warning message appears in Alarmlist: "RTCbatteryFlat".
After the next power switch on (with flat battery already) controller:
Stays in the INIT state (not possible to run genset)
All History records disappear except of “System log: SetpointCS err” record
Time and Date values are set to zero
Statistics values are random
20.2. Operating conditions
IG-NT, IG-NTC, IM-NT -20 +70°C
IG-NT-LT, IG-NTC-LT, IM-NT-LT -40 +70°C
IS-NT-system** operating temperature -20..+70
o
C *
IS-NT-BB operating temperature -40..+70
o
C *
IG/IS/IM BB NT and NTC versions (operating temperature) -30 +70°C
IG/IS/IM BB NT and NTC versions (storage temperature) -40 +80°C
IS-NT*** operating temperature (LT version) -40..+70
o
C *
Storage temperature -30..+80
o
C
