IGS-NT Installation Guide

137

AVRi+

AVRi-

18VAC

From

generator

OUT1

AVRi

230/400VAC

0VAC

AVRI COM

AVRI OUT

IG- AVRi

TRANS

IG-

OUT2

Volt/PF ctrl:

AVR DCout bias = 50%

VoltRegChar = POSITIVE

SINCRO AVR BL4 or AVR BL3

AVRi+

AVRi-

18VAC

From

generator

OUT1

AVRi

230/400VAC

0VAC

AVRI COM

AVRI OUT

IG- AVRi

TRANS

IG-

COM

POT

EXT

AVRi trim to middle position

Volt/PF ctrl:

AVR DCout bias = 20%

VoltRegChar = NEGATIVE
