Mounting procedure: dimensions, space and handling
21
HS-RC-C5E-TIN_02.fm
00/0411
3. MOUNTING PROCEDURE:
DIMENSIONS, SPACE AND HANDLING
This chapter deals with the following topics:
– Precautions before starting the procedure
– Equipment and tools required
– Packing list check
– Weight and size including package
– Overall dimensions and installation space required for the C5G (without
conditioner)
– Overall dimensions and installation space required for the C5G (with conditioner)
– Lifting and handling procedures
– Procedure to remove the crate, protection cloth and pallet
– Placing in position.
3.1 Precautions before starting the procedure
Before starting the handling procedure, please read carefully the notes in
Chap. Installation instructions on page 19.
3.2 Equipment and tools required
– Lifting equipment suitable for the installation area (crane or lift truck)
– Eyebolts (supplied together with the Control Unit and already fastened on the
cover, featuring EC mark).
– 13-mm socket wrench
3.3 Packing list check
Inside the cabinet is a STANDARD PRODUCT LIST.
Make sure all components in the list are available.
