Mounting procedure: dimensions, space and handling
35
HS-RC-C5E-TIN_02.fm
00/0411
3.9 Placing in position
a. Place the cabinet on the floor
b. If the cabinet is not supplied with wheels go to step d.
c. If the cabinet is supplied with (optional) wheels:
c.1 move to position pushing carefully.
c.2 lock the wheels acting on the special lever on the wheels themselves.
d. Make sure the minimum space requested around the C5G fulfil the requirements
specified in
par. 3.5 Overall dimensions and installation space required for the C5G
(without conditioner) on page 26.
e. Make sure not to hinder the warm air circulation and ensure the area above the
Control Unit is free
f. We do not recommend to remove the eyebolts. If they have to be removed:
– keep the eyebolts inside the cabinet. In case of later lifting, use only the
eyebolts supplied or anyway featuring the EC mark.
– Do not remove the plastic washer.
– To lock the Control Unit cover use 4 M12 nuts (not supplied) in the place of
the eyebolts. Tighten the nuts but do not force them. To keep the protection
class IP54 unaltered the nuts are to be installed properly.
g. Do not place any item over the Control Unit.
When moving the cabinet with wheels over long stretches, act
extremely carefully as small obstacles may cause the cabinet
overturning.
