Powering supply from the mains: features and connection
36
HS-RC-C5E-TIN_03.fm
00/0211
4. POWERING SUPPLY FROM THE MAINS:
FEATURES AND CONNECTION
This chapter deals with the following topics:
– Precautions before starting
– Equipment and tools required
– Power supply features
– Earth connection diagram
– Selecting the powering voltage
– Procedure to install and connect the powering cable (on Main Circuit breaker)
4.1 Precautions before starting
Before carrying out the connection to the power supply, read carefully the notes in
Chap. Installation instructions on page 19.
Before performing the connection activities described in this chapter switch OFF (0
position) the main switch and cut off the source of power.
4.2 Equipment and tools required
– 5.5 x 1 blade screwdriver
– 8-mm socket wrench
– Clip for lugs.
Operating procedure
a. Position the main switch Q100
lever (A) on OFF (0).
Before carrying out the connections, make sure the powering line is
not powered.
