Figure 2–39: Interconnecting The DVA Device
DVA003
TAPE IN
STATION
RESET
DVA01
PWR IN USE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
CLIP TERMINALS
50
26
1
25
{
Typical Station
Connector Block
Station Jack Pin-Out
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
No Connection
No Connection
Tip 1
Ring 1
No Connection
No Connection
25-Pair
Male To
Female
Cable
(Typical)
To Common
Equipment
Cabinet
654321
TI
RI
R2T2
GREEN RED
FRONT
VIEW
OF JACK
1 NO CONNECTION
2 NO CONNECTION
3 RI-RED-VOICE
4 TI-GREEN-VOICE
5 NO CONNECTION
6 NO CONNECTION
STATION
SITE
Typical Station
Wall Jack Wiring
6
5
4
1
2
3
Audio Tape Recorder
For DSU installations,
connect to DVA01's
tape in jack.
IMI66–107 Digital Telephone System
Installing The DSU 2 – 79
