2.14.1 Expansion Capabilities
The 4-line 8-station expansion module adds station and line capability in several different
combinations.
Figure 2–20: Add-On Expansion Module Capabilities
16-Line, 32-Station Base Unit
4-Line, 8-Station Base Unit
8-Line, 16-Station Base Unit
24-Port System
8-LINES AND 16-STATIONS
(BASE UNIT PLUS ONE EXPANSION MODULE)
36-Port System
12-LINES AND 24-STATIONS
(BASE UNIT PLUS ONE EXPANSION MODULE)
48-Port System
60-Port System
72-Port System
16-LINES AND 32-STATIONS
(BASE UNIT PLUS TWO EXPANSION MODULES)
20-LINES AND 40-STATIONS
(BASE UNIT PLUS ONE EXPANSION MODULE)
24-LINES AND 48-STATIONS
(BASE UNIT PLUS TWO EXPANSION MODULES)
