Figure 2–1: Cabinet Dimensions
CAJS044A
4.54"
3.78"
3.78"
16.50"
16.50"
16.50"
27.58"
27.58"
21.30"
0.88"
0.87"
26.65"
26.25"
20.50"
Back of
16-Line, 32-Station
Base Unit
Back of
8-Line, 16-Station
Base Unit
Back of
4-Line, 8-Station
Base Unit
4-Line, 8-Station Base Unit
8-Line, 16-Station Base Unit
16-Line, 32-Station Base Unit
0.88"
IMI66–107 Digital Telephone System
Installing The DSU 2 – 7
