Comdial G0408 - Page 52

Table 2–6: Connecting Stations To J2 On The G1632 Common Equipment Cabinet
25-Pair Connections Two-Wire Connections Station Connections
Wire Color Pair Pin No.
Clip
Term.
Pair Wire Color Station Location
White-Blue
1
26 1
Signal Path
Green
26
Blue-White 1 2 Red
White-Orange
2
27 3
Signal Path
Green
27
Orange-White 2 4 Red
White-Green
3
28 5
Signal Path
Green
28
Green-White 3 6 Red
White-Brown
4
29 7
Signal Path
Green
29
Brown-White 4 8 Red
White-Slate
5
30 9
Signal Path
Green
30
Slate-White 5 10 Red
Red-Blue
6
31 11
Signal Path
Green
31
Blue-Red 6 12 Red
Red-Orange
7
32 13
Signal Path
Green
32
Orange-Red 7 14 Red
Red-Green
8
33 15
Signal Path
Green
33
Green-Red 8 16 Red
Red-Brown
9
34 17
Signal Path
Green
34
Brown-Red 9 18 Red
Red-Slate
10
35 19
Signal Path
Green
35
Slate-Red 10 20 Red
Black-Blue
11
36 21
Signal Path
Green
36
Blue-Black 11 22 Red
Black-Orange
12
37 23
Signal Path
Green
37
Orange-Black 12 24 Red
Black-Green
13
38 25
Signal Path
Green
38
Green-Black 13 26 Red
Black-Brown
14
39 27
Signal Path
Green
39
Brown-Black 14 28 Red
Black-Slate
15
40 29
Signal Path
Green
40
Slate-Black 15 30 Red
Yellow-Blue
16
41 31
Signal Path
Green
41
Blue-Yellow 16 32 Red
Yellow-Orange
17
42 33
Orange-Yellow 17 34
Yellow-Green
18
43 35
Green-Yellow 18 36
Yellow-Brown
19
44 37
Brown-Yellow 19 38
Yellow-Slate
20
45 39
Slate-Yellow 20 40
Violet-Blue
21
46 41
Blue-Violet 21 42
Violet-Orange
22
47 43
Orange-Violet 22 44
Violet-Green
23
48 45
Green-Violet 23 46
Violet-Brown
24
49 47
Brown-Violet 24 48
Violet-Slate
25
50 49
Slate-Violet 25 50
