Compal JHL90 - 1.4 Optical Drive (ODD) Disassembly

JHL90 Service Manual
1.4 Disassembling the ODD (CD-ROM/DVD-ROM/CD-RW…)
2. Remove three screws securing and remove the thermal cover upward.
Follow the steps below to disassemble the optical drive (ODD):
1. Turn the notebook upside down.
3. Remove the screw and insert a flat screwdriver into the slot as shown and
gently push out the ODD.
5-7
