JHL90 Service Manual
10. System Setup
10.1 Invoking setup
The setup function can be invoked by pressing F2 when “Press <F2> to enter
Setup” message is prompted on the bottom of screen during POST or by selecting
<Enter Setup> in Boot Menu after pressing F12.
During setup, all Fn function keys and power saving functions are disabled.
10.2 Setup screens
10.2.1 Main Menu
Phoenix SecureCore(tm) Setup Utility
Main
System Time: [HH:MM:SS]
System Date: [MM/DD/YYYY]
Product Name: XXXXXXX
Serial Number: XXXXXXXXXXXXX
System Memory: 640 KB
Extended Memory: XXXX MB
BIOS Version: X.XX
UUID Number: XXXXXXXXXXXXX
XXXXXXXXXXXXX
F1 Help ↑↓ select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→ select menu Enter Select 4 Sub-Menu F10 Save and Exit
System Time and System Date
The hour is displayed with 24-hour format. The values set in these two fields take effect
immediately.
Product Name, Serial Number
Display product name, serial number.
2-15
