Compal JHL90 - EC Name Space Configuration

JHL90 Service Manual
Number lock on Number lock off
* 0
4 U
5 I
6 O
- P
1 J
2 K
3 L
+ ;
0 M
, ,
. .
/ /
12.17 EC name space Configuration
12.17.1 Customer EC name space definition
Offset Description
00h - 07h
Customer EC name space
12.17.2 Project EC name space definition
Offset Description
08h - 0Fh
Project EC name space
12.17.3 SMBus EC interface ACPI RAM definition
Offset Description
60h
SMBus protocol
61h
SMBus statue
Bit0-Bit4 - Status
Bit5 - Reserved
Bit6 - ALARM
Bit7 - DONE
62h
SMBus Address
63h
SMBus Command
64h - 83h
SMBus Data
84h
SMBus BCNT
85h
SMBus alarm address
86h
SMBus alarm data 0
87h
SMBus alarm data 1
2-37
