JHL90 Service Manual
In this status, when user pressed Fn+F2, AP will be showed user that cannot
turn on Wireless LAN and Bluetooth.
If the devices just only have one whatever Wireless LAN or Bluetooth, the
AP won’t be showed anything.
12.5 External Buttons status report and control
12.5.1 Power Switch (Push button)
If system is Off/S2D: System will be turned on while Power switch is depressed
by more than 500 ms with or without AC insert
• If system is in S2R/Standby state: System will resume while Power switch is
depressed by more than 100 ms
12.5.2 Mail Button (No Support)
• Open outlook or express AP.
12.5.3 Internet Button (No Support)
• Open Internet explorer AP.
12.5.4 User defined Button (No Support)
• User can defined which function they want to use.
12.5.5 Program Button (No Support)
• User can defined which AP they want to use.
12.5.6 WOW Audio Button (Just support in high-end platform)
• Open WOW Audio’s AP.
12.5.7 WOW Video Button (Just support in high-end platform)
• Open WOW Video’s AP.
12.5.8 Smart Key Button
• Open Smart Key’s AP.
12.5.9 Power USB Button
In S3 mode AC + BATTERY AC only BATTERY only
JHT0x_JHL9x Support Support Support
• Power USB Button also be supported in S3 and S5 mode
12.6 IOMP button
12.6.1 Mode Button
• Open the Media player under Windows mode.
12.6.2 Next One Button
• Press/Release short than 2 sec: Next One
• Press/Release more than 2 sec: Volume Up
2-29
