Compal JHL90 - System Features and Power

JHL90 Service Manual
Web Cam
JHL90/JHT00:
– 2.0M pixel CMOS via USB 2.0 interface.
 Auto-focus (ME dimension).
 Face detect function (Compal SW).
 Business card scanner.
 A4 scanner.
JHL91/JHT01:
– 1.3M/2.0M pixel CMOS via USB 2.0 interface. (option)
 Auto-focus (ME dimension).
 Face detect function (Compal SW).
 Business card scanner.
 A4 scanner.
I/O Ports
– PCI-Express Card, 34/54mm. x 1
– USB V2.0, x 3, Power USB V2.0 x 3
– RGB; VGA port x 1, 15pins
– S-Video in x 1
– Microphone-in x 1
– Headphone-out jack x 1
– DC-in jack x 1
– Mini Card x3 (JHL90) / Mini Card x2
(JHL91/JHT01/JHT00)
– Media Card Reader (SD/MMC/MS/MS pro) x 1
– RJ-11 jack x 1 for 56Kbps V.90/92 Modem x 1
– RJ-45 jack x 1
– Kensington lock x 1
– HDMI x 1
– RF-in x 1 (option)
User keys
– Power Button. x 1
– Magnetic Lid Switch. x 1
– Wireless switch x 1
– Power USB Button x 1
– Program DJ x 1
– JHL90/JHT00: Wow Video. Four modes: Movie, Photo,
Office, Nature x 1
– JHL90/JHT00: Wow Audio.
Security
– JHL90/JHT00: Fingerprint
TPM 1.2 by Infineon/Winbond
 Design ready for Windows Vista
– Kensington lock
Controls
– Power button x 1
– Magnetic lid switch control for system standby or suspend
AC adapter
– Universal AC Adapter, 19V DC, 3 pins 240V 90W and
65W
