JHL90 Service Manual
12.8.3 Definitions of AC LED ( )
• Please refer PDD document.
12.8.4 Definitions of HDD accessing state Blue LED (
)
• Please refer PDD document.
12.8.5 Definitions of Bluetooth state LED
• Please refer PDD document.
12.8.6 Definitions of Wireless State LED
• Please refer PDD document.
12.8.7 Definitions of Battery state LED (
)
• There is one dual-color LED indicator both of Blue and Amber color.
• LED colors and definition
• Blue color and Amber color defined for battery charging and discharging state.
The definition as below:
Battery State LED colors Description
Blue and blinking
(ON 1S, OFF 1S)
Battery charging with AC.
Blue solid on Battery full by AC charge and stop
charging.
Charging
Amber and blinking
(ON 500mS, OFF
500mS)
Battery abnormal stop charging with
AC.
Abnormal stop charging: BadCell,
OverTemp, communication fail and
OVP.
Blue color off
Amber color off
Battery in discharge mode.
Discharging
Amber solid on Battery within low state.
(Battery gas-gauge ≤8%)
• When the battery is in critical low state, the system is protected and can’t be
re-powered on without the AC power connected. In this situation, the LED
will be in amber color for a short time to indicate this condition. Keep
depressing the power button, and the LED will be blinking in amber color
12.8.8 Definitions of WOW Audio, Video, Smart Key state LED - High-end
platform
• Please refer PDD document.
12.8.9 Definitions of WOW Audio, Video, Smart Key state LED - Low-end
platform
• Please refer PDD document.
12.8.10 Definitions of Power USB state LED
• Please refer PDD document.
2-31
