JHL90 Service Manual
Battery Configuration 3S2P 3S2P 3S3P
Battery Nominal Voltage
(V)
11.1 11.1 11.1
Single Cell Chemistry Li-ion Li-ion Li-ion
Single Cell Type 18650 18650 18650
Single Cell Capacity
(mAH)
2400 2600 2400
Dumb/Smart Battery Smart Battery
(SMBus ver. 1.1.)
Smart Battery
(SMBus ver. 1.1.)
Smart Battery
(SMBus ver. 1.1.)
Cycle Life 70% after 300
cycles
70% after 300 cycles 70% after 300 cycles
Nominal Charging
Voltage (V)
12.6 12.6 12.6
Nominal Charging Current
(A)
3 3 3
Protection Function OVP
UVP
OTP
OCP
OVP
UVP
OTP
OCP
OVP
UVP
OTP
OCP
1-2. Battery Connector Pin Assignment
Connector Male on M/B: TBD
Connector Female on Battery: SUYIN-200274FS009GX01ZU
Pin No. Symbol Comments
1 BATT+ Batt+, Battery Positive Terminal.
2 BATT+ Batt+, Battery Positive Terminal.
3
ID Identify pin (Note 1)
4 B/I Battery-In pin (Note 2)
5 SMC SMBus clock interface I/O pin.
6 SMD SMBus data interface I/O pin.
7 TS Connect to thermister (Note 3)
8 GND Battery Negative Terminal.
9 GND Battery Negative Terminal.
Note: 1. ID pin must be floating.
2. The battery can be charged/discharged only while this pin is connected to GND
by the system.
3. Thermister: DTN-C103F3H-SYS115A (or 103AT2 equivalent).
The other thermister Pin is connected GND.
