JHL90 Service Manual
17
Turn off
voltage
(Low side)
Voff -- --
150Vp-
p
V PWM=30%
18
Voltage Rise
time (Low
side)
Trise -- -- 300us us PWM=30%
19
Voltage fall
time (Low
side)
Tfall -- -- 300us us PWM=30%
Notes:
• The inverter can work in 7.5V input voltae (continuous), but 7.5V electronic
characteristic will not be care. (Note: the display must be normal and can not
glitter or become dark)
• Limited lamp maximum current by DAC_BRIG signal:
When DAC_BRIG voltage is 0V and INV_PWM enables (100%), lamp has
max.-limited current.
When DAC_BRIG voltage is 3.3V and INV_PWM enables (100%), lamp has
min.-limited current.
When add 1V DAC, the 100% Lamp current will decrease 0.5mA.
DAC_BRIG signal comes from system chipset with internal resistance of 3KΩ.
• Inverter operating frequency should be within specification (45~65kHz) at
max. and min. brightness load.
• INV_PWM enable implies INV_PWM signal is High level (On duty cycle is
100%). It is a square wave of 150Hz to adjust backlight brightness that is a
function of PWM duty cycle. Backlight brightness is maximum value under
INV_PWM at 100% and brightness is minimum under INV_PWM at 30%.
• The system interface signals belong to 3.3V.
• Please make sure open lamp output voltage should be within starting voltage
specification.
• Inverter should pass human body safety test.
• Inverter should no smoking by any component open / short test
• Transformer voltage stress should not be over 85% under any condition (turn
on overshoot transient and line transient).
• Audio noise should be less than 36dB at 10 cm distance.
4-14
