JHL90 Service Manual
Time Table
Control Item Min. Max. Spec. List
T1
5ms ICH9 output 11450/Figure19-21, Table19-20, T173
T2
50ns ICH9 output 11450/Figure19-21, Table19-21, T181
T3
110ms ICH9 output 11450/Figure19-21, Table19-21, T182
T4
110ms ICH9 output 11450/Figure19-21, Table19-21, T183
T5
10ms 40ms EC control, SYSON active to
SUSP# active time.
T6
50ns ICH9 output 11450/Figure19-21, Table19-21, T184
T7
10ms 40ms EC control, SYSON active to
SUSP# active time.
T8
10ms Base on system design 11450/Figure19-21, Table19-20, T176
T9
1ms 10ms GMCH and ICH9 output
Reference document list
REF. NO. Document Title REV. NO.
11450 Intel
®
I/O Controller Hub9 (ICH9) External Design Specification 1.1
11743 Mobile Intel
®
Pentium
®
4 Processor-M and Intel
®
chipset
Platform Recommended Design & Debug Practices.
0.7
4-22
