CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
Specify TCP/UDP destination port
[MIN] (1 - 65535)<Enter: ***>
1 -
65535
Enter desired TCP/UDP destination port (or Min port of a range).
If no TCP/UDP destination port is desired, select enter,
Destination port will be displayed as ‘***’.
Specify TCP/UDP destination port
[MAX] (1 - 65535)<Enter: ***>
1 -
65535
Enter desired TCP/UDP destination port (or Max port of a range).
Will not display if no MIN TCP/UDP destination port was selected.
Set WRED (Weighted Random Early
Discard) <Y or N><Enter : Y>
Y or N Select to enable Weighted Random Early Detect.
Specify Filtering for the rule <Y or
N><Enter : N>
Y or N Select to prevent traffic defined in rule to be forwarded.
Default N = not filtered
Delete D Enter the QoS Rule to delete <1..32>
Base [1] B Select Base to view, edit, or display a different set of 8 QoS
Rules. For example, if 8 QoS Rules have been defined, add a
new rule by selecting B 9. The QoS Configuration page will
refresh and now display QoS Rules 9 – 16.
QoS [ ] Read
Only
Displays state of QoS option – Unavailable, Enabled Disabled. If
available, QoS is Enabled or Disabled from the Administrator
Features Page.
Save Parameters S This option allows a user to save the current configuration to
permanent storage. This configuration will be restored on each
successive power cycle.
Exit X This option allows a user to exit the current menu and return to its
parent menu.
17–29
