17.2.8.3 Framing Mode Configuration
The Framing Mode Configuration page is activated from the Configuration page.
The Framing Mode Configuration page contains the following options/fields:
Menu Options/Fields Entry Description
Framing Mode
F
1 -- Unframed
2 -- EDMAC Framing
3 -- EDMAC-2 Framing
EDMAC Mode
D
1 -- Unframed
2 -- EDMAC Framing
3 -- EDMAC-2 Framing
EDMAC Slave Address Range
V
10 to 9990 in multiple of ten.
AUPC
A
1 -- Enable
2 -- Disable
Max Power Reached Action
R
1 -- No_Action
2 -- Generate_TX_Alarm
Remote Demod Unlock Action
U
1 -- Nominal_Power
2 -- Maximum_Power
Target Eb/No of Remote Demod
(db)
E
0.0 to 9.9
Maximum Power Limit
M
0 to 9
