CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.3.18 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER)
FREQUENCY
ODU Rx Frequency:
3912.5 MHz (◄ ►,▲ ▼,ENT)
The user is prompted to edit the receive frequency. This is accomplished by selecting the
digit to be edited, using the
◄ ► arrow keys. The value of the digit is then changed
using the
▲ ▼ arrow keys. The user then presses ENT.
F.3.3.19 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) ATTEN
(Attenuation)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) ATTEN
(Attenuation)
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) ATTEN
(Attenuation)
ODU Rx Attenuation:
15.00 dB (◄ ►,▲ ▼,ENT)
The user is prompted to edit the receive attentuation. This is accomplished by selecting
the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed
using the ▲ ▼ arrow keys. The user then presses ENT.
F.3.3.20 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) MUTE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) MUTE
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) MUTE
ODU Rx Mute State:
Muted Unmuted (◄ ►,ENT)
The user is prompted to select either Muted or Unmuted, using the
◄ ► arrow keys,
then to press ENT.
F–8
