CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.3.21 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) SLOPE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) SLOPE
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) SLOPE
ODU Rx Slope Mode:
Manual Calibrated (◄ ►)
The user is prompted to select either Manual or Calibrated, using the ◄ ► arrow keys,
then to press ENT.
F.3.3.22 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER,SLOPE)
MANUAL
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER,SLOPE)
MANUAL
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER,SLOPE)
MANUAL
ODU Rx Slope:
0.0 (▲ ▼,ENT)
If Manual mode is selected, the user is prompted to edit the transmit slope setting. This
is accomplished using the
▲ ▼ arrow keys. The user then presses ENT.
F.3.3.23 (ODU,ENABLE,1:1,CSAT#1,CONFIG) MISCELLANEOUS
(ODU,ENABLE,1:1,CSAT#2,CONFIG) MISCELLANEOUS
(ODU,ENABLE,STAND-ALONE,CONFIG) MISCELLANEOUS
MISC: Cold-Start AFR LNA
XRef Ref-Adjust RTC (◄ ►)
This menu item is used to select miscellaneous ODU parameters for modification. Use
the ◄ ► arrow keys, then press ENT.
F–9
