F.3.3.37 (ODU,ENABLE,1:1,CSAT#1,INFO) RECEIVER
(ODU,ENABLE,1:1,CSAT#2,INFO) RECEIVER
(ODU,ENABLE,STAND-ALONE,INFO) RECEIVER
Rx: ON 3625.0MHz 10.00dB
Unmuted Sl:0.0
This window provides the CSAT Receiver information including receiving status,
Rx Frequency, Rx Attenuation, Rx Mute state and Rx Slope adjustment. Press ENT.
F.3.3.38 (ODU,ENABLE,1:1,CSAT#1,INFO) LNA
(ODU,ENABLE,1:1,CSAT#2,INFO) LNA
(ODU,ENABLE,STAND-ALONE,INFO) LNA
LNA: On Window: 99%
Fault Logic: No-Summary
This window provides the current state of the LNA functions. Press ENT.
F.3.3.39 (ODU,ENABLE,1:1,CSAT#1,INFO) MISC
(ODU,ENABLE,1:1,CSAT#2,INFO) MISC
(ODU,ENABLE,STAND-ALONE,INFO) MISC
Cold Start: Off
Auto Fault Recovery: On
This window provides the current state of the Cold Start and Auto Fault Recovery
functions. Press ENT.
F.3.3.40 (ODU,ENABLE,1:1,CSAT#1) MONITOR
(ODU,ENABLE,1:1,CSAT#2) MONITOR
(ODU,ENABLE,STAND-ALONE) MONITOR
ODU MONITOR: Tx Rx Misc
Pwr-Supp1 Pwr-Supp2 (◄ ►)
The operator uses this menu item to select enter 1 of 5 ‘Monitor Windows’. Use the
◄ ► arrow keys, then press ENT.
