CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.3.41 (ODU,ENABLE,1:1,CSAT#1,MONITOR) TX (Transmitter)
(ODU,ENABLE,1:1,CSAT#2,MONITOR) TX (Transmitter)
(ODU,ENABLE,STAND-ALONE,MONITOR)TX (Transmitter)
TX: SynTune=04.8 Pwr=040
IFLO = 10.7 Temp = 27
o
C
This window provides the Tx Synthesizer and IFLO tuning voltages, the RF Output
Power in dBm and the Transmitter temperature. Press ENT.
F.3.3.42 (ODU,ENABLE,1:1,CSAT#1,MONITOR) RX (Receiver)
(ODU,ENABLE,1:1,CSAT#2,MONITOR) RX (Receiver)
(ODU,ENABLE,STAND-ALONE,MONITOR)RX (Receiver)
RX: Synth Tune = 03.1
IFLO = 10.9 Temp = 28
o
C
This window provides the Rx Synthesizer and IFLO tuning voltages and the Receiver
temperature. Press ENT.
F.3.3.43 (ODU,ENABLE,1:1,CSAT#1,MONITOR) MISC
(ODU,ENABLE,1:1,CSAT#2,MONITOR) MISC
(ODU,ENABLE,STAND-ALONE,MONITOR)MISC
MISC: Ref Tune = 03.0
LNA=000.0mA FAN=568.0mA
This window provides the Internal Reference Oscillator tuning voltages, the LNA Current
in milliamps and the Fan Current in milliamps. Press ENT.
F.3.3.44 (ODU,ENABLE,1:1,CSAT#1,MONITOR) PWR SUPP1
(ODU,ENABLE,1:1,CSAT#2,MONITOR) PWR SUPP1
(ODU,ENABLE,STAND-ALONE,MONITOR) PWR SUPP1
PS: 24V=23.8 20V=22.6
12V=13.0 10V=10.1
This window provides a monitor for four of the six internal power supplies. Press ENT.
F–15
