CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.3.45 (ODU,ENABLE,1:1,CSAT#1,MONITOR) PWR SUPP2
(ODU,ENABLE,1:1,CSAT#2,MONITOR) PWR SUPP2
(ODU,ENABLE,STAND-ALONE,MONITOR) PWR SUPP2
PS: +5V=5.5 -5V=-4.9
This window provides a monitor for the remaining two internal power supplies. Press
ENT.
F.3.3.46 (ODU,ENABLE,1:1,CSAT#1) ALARMS
(ODU,ENABLE,1:1,CSAT#2) ALARMS
(ODU,ENABLE,STAND-ALONE) ALARMS
ALARMS: Current Stored
(◄ ►,ENT)
The operator uses this menu item to view either Current Alarm Status or the Stored
Alarms Log. Use the ◄ ► arrow keys, then press ENT.
F.3.3.47 (ODU,ENABLE,1:1,CSAT#1,ALARMS) CURRENT
(ODU,ENABLE,1:1,CSAT#2,ALARMS) CURRENT
(ODU,ENABLE,STAND-ALONE,ALARMS)CURRENT
TX = OK RX = OK
PWR SUP = OK MISC = OK
The operator uses this menu item to view Current Alarm Status. This window provides
a summary of the current CSAT status. If any of the 4 items displays “FT,” the operator
should view the Stored Alarms Log for details.
F.3.3.48 (ODU,ENABLE,1:1,CSAT#1,ALARMS) STORED
(ODU,ENABLE,1:1,CSAT#2,ALARMS) STORED
(ODU,ENABLE,STAND-ALONE,ALARMS) STORED
Stored Events: View
Clear All (◄ ►,ENT)
The operator uses this menu item to either View or Clear All the Stored Events Log
using the ◄ ► arrow keys, then press ENT.
F–16
