50 Condair CRC and CRC-NA
3.8.6 Connecting the CRC or CRC-NA to the Condair SE
1. Connect the CRC or CRC-NA to the corresponding terminals of the Condair SE according to the
appropriate wiring diagram (see below).
Note: The voltage supply of the CRC or CRC-NA is established via the terminals "24 VAC" and
"Ground" of the terminal block or via an external 24 V AC/DC voltage supply.
12
11
10
9
8
76
54
321
24VAC 0-10V VDC Out On/Off Loop Ground Actuator Power Actuator Power Control Signal Limit Signal (SETC only) Full Tank Blowdown Ground Ground 5 VDC
Condair SE
12
11
10
9
8
76
54
321
24VAC 0-10V VDC Out On/Off Loop Ground Actuator Power Actuator Power Control Signal Limit Signal (SETC only) Full Tank Blowdown Ground Ground 5 VDC
Condair SE
24V AC/DC 0V/GND A0 2-10V
1 2 3 4 5 6 7 8
***
0...10V
JP1
2
3
1
JP3
2
3
1
24V AC/DC 0V/GND H OUT
JP1
2
3
1
JP3
2
3
1
***
1 2 3
24 VAC 24 VAC
CRC
CRC-NA
2. Only for CRC: Set the output signal of the CRC to "0-10V" using the Jumpers JP1 and JP3 on the
control board of the CRC.
Note: other output signal settings (e.g. 4-20mA) are also possible, see CRC jumper settings in Sec-
tion 3.7.
