The CMS 8 000 P atient Monitor is intended for use in the electromagnetic environment specified below.
The customer or the user of CMS 8 000 P atient Monitor should assure that it is used in such an
environment .
Immunity
Immunity
Immunity
Immunity
test
test
test
test
IEC60601
IEC60601
IEC60601
IEC60601 test
test
test
test
level
level
level
level
Compliance
Compliance
Compliance
Compliance
level
level
level
level
Electromagnetic
Electromagnetic
Electromagnetic
Electromagnetic
environment-guidance
environment-guidance
environment-guidance
environment-guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
± 6 k V contact
± 8 k V air
± 6 k V contact
± 8 k V air
Floor s should be wood, concrete
or ceramic tile. If floor are
c overed with synthetic material,
the relative humidity should be
at least 30% .
Electrical fast
transient/burst
IEC 61000-4-4
± 2k V for power
supply lines
± 0.5k V for power
supply lines
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
± 1k V differential
mode
± 2k V common
mode
± 1k V differential
mode
± 2k V common mode
Mains power quality should be
that of a typical commercial or
hospital environment.
Power frequency
(50 /60 Hz) magnetic
field
IEC 61000-4-8
3A/m 3A/m Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical commercial
or hospital environment
Voltage dips,short
interruptions and
voltage vatiations on
power supply input
lines
IEC 61000-4- 11
<5%U
T
(>95%dip in
U
T
) for 0.5 cycle
40% U
T
(60%dip in
U
T
) for 5 cycle
70%U
T
(30%dip in
U
T
) for 25 cycle
<5%U
T
(>95%dip in
U
T
) for 5 sec
<5%U
T
(>95%dip in
U
T
) for 0.5 cycle
40% U
T
(60%dip in
U
T
) for 5 cycle
70%U
T
(30%dip in
U
T
) for 25 cycle
<5%U
T
(>95%dip in
U
T
) for 5 sec
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the CMS8000 Patient Monitor
requires continued operation
during power mains
interruptions, it is recommended
that the CMS8000 Patient
Monitor be powered from an
uninterruptible power supply or
a battery.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.

Contec CMS8000 Specifications

General

Category	Medical Equipment
Device Name	Contec CMS8000
Type	Patient Monitor
ECG Lead Mode	3-lead or 5-lead
Resolution	800 x 600
Power Supply	AC 100-240V, 50/60Hz
Battery	Rechargeable lithium battery
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 55°C
Display	TFT LCD
Screen Size	12.1 inches
Parameters	ECG, RESP, NIBP, SpO2, TEMP, PR
Interface	Ethernet, Nurse call
Humidity	15% to 95% non-condensing
Battery Life	Approximately 4 hours
