Contec CMS8000 Manual

-
-
-
- 50 -
-
-
-
2. ALARM RECALL EVENT
In the pull-down list of ALARM RECALL EVENT, the user can select the parameter whose alarm
events he wants to review. The selections include ALL(alarm events of all parameters), ECG ,
RES P , S PO
2
, NIBP, IBP,TEMP,CO
2
.
After setting up all the review conditions, press the “ ALARM RECALL ” button to access “ ALARM
RECALL ” window.
 ALARM RECALL
The ALARM RECALL window is as shown below, in which following data are displayed:
1
Time span (Format: month-day-year hour: minute- month-day-year hour: minute ) .
2
Event type.
3
Serial number (Format: NO. xx of XX ).
4
The value at the time of alarm. NIBP result is with time.
5 Two 8/16/32 -second waveforms.
①
②
④
③
⑤
Figure
Figure
Figure
Figure 7-
7-
7-
7- 5
5
5
5 ALARM
ALARM
ALARM
ALARM RECALL
RECALL
RECALL
RECALL Menu
Menu
Menu
Menu
To
To
To
To view
view
view
view all
all
all
all waveforms
waveforms
waveforms
waveforms during
during
during
during the
the
the
the alarm
alarm
alarm
alarm ing
ing
ing
ing process
process
process
process
Pick L-RIGHT and turn the knob to view all 8/16/32- second waveforms stored.
To
To
To
To view
view
view
view other
other
other
other alarm
alarm
alarm
alarm events
events
events
events
Events of up to 71 are listed chronologically from the latest to the earliest. Pick UP-DOWN button and
turn the knob to view later or earlier events.
Recording
Recording
Recording
Recording
Pick REC to print our all data and waveform of this event.

Contec CMS8000 Specifications

General

Category	Medical Equipment
Device Name	Contec CMS8000
Type	Patient Monitor
ECG Lead Mode	3-lead or 5-lead
Resolution	800 x 600
Power Supply	AC 100-240V, 50/60Hz
Battery	Rechargeable lithium battery
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 55°C
Display	TFT LCD
Screen Size	12.1 inches
Parameters	ECG, RESP, NIBP, SpO2, TEMP, PR
Interface	Ethernet, Nurse call
Humidity	15% to 95% non-condensing
Battery Life	Approximately 4 hours
