FM-3 Programming Module Reference Manual
Drive Input Debounce Time
DriveInput.#.DebounceTime
The Drive Input Debounce Time parameter is the minimum time a digital input must be
steady in order to be recognized by the FM-3. This feature helps prevent false triggering in
applications in electrically noisy environments.
Drive Input Force
DriveInput.#.Force
Input can be forced either On or Off. This parameter is the state to which the input will be
forced when the ForceEnable bit is activated.
Drive Input Force Enable
DriveInput.#.ForceEnable
If DriveInput.#.ForceEnable parameter is activated, then the state of the DriveInput.#.Force
bit will override the current input state.
Drive Input Name
DriveInput.#.Name
This is a text string up to 12 characters that can be assigned to a given input. It allows the user
to use application specific terminology in naming digital inputs.
Drive Input Raw
DriveInput.#.Raw
This displays the raw state of the digital input without debounce or forcing to override the raw
status.
Drive Input Status
DriveInput.#.Status
This source is the state of the input after debounce and forcing are taken into account.
Drive Output Force
DriveOutput.#.Force
A drive output can be forced either On or Off with this parameter. If the ForceEnable bit is
activated, the DriveOutput.#.State will be set to this value.
