167
Parameter Descriptions
Command In Progress
Jog.#.CommandInProgress
The Jog.#.CommandInProgress source is high throughout an entire jog profile. The bit goes
high at the start of a jog acceleration ramp, and turns off at the end of a jog deceleration ramp.
Deceleration
Jog.#.Decel
This parameter is the average deceleration ramp for the specific jog.
Decelerating
Jog.#.Decelerating
This source turns on at the beginning of a jog deceleration ramp and turns off at the
completion of the ramp.
Initiate Minus
Jog.#.MinusInitiate
This is used inside a program to initiate a specific jog. When this bit is active, jogging motion
will be initiated in the negative direction at the specified jog velocity.
Initiate Plus
Jog.#.PlusInitiate
This is used inside a program to initiate a specific jog. When this bit is active, jogging motion
will be initiated in the positive direction at the specified jog velocity.
Time Base
Jog.#.TimeBase
The time base selects either realtime, which allows velocities, acceleration and deceleration
to be based on real time, or synchronized, which allows for an external synchronization
signal.
Velocity
Jog.#.Vel
This parameter specifies the velocity used for jogging with the Jog.PlusActivate and
Jog.MinusActivate destinations or the Jog.#.PlusInitiate and Jog.#.MinusInitiate inside a
program. The units for this parameter are specified in the User Units view.
