UD70
Issue code: 70nu2
Parameters 10-1
10 Parameters
10.1 UD70 set-up parameters
The set-up parameters take effect only after the UD70 has been reset. This
occurs when any of the following actions is performed:
AC supply is applied to the Drive
A
REINIT instruction in a DPL program is executed
When Reset TargetReset Target is selected in the RunRun menu in the DPL Toolkit
The value 1070 is written to parameter #88.01
The following table lists all the
UD70 set-up parameters.
Function Parameter Min Value Max Value Default
Large Option Module
code
#17.01 N/A N/A 1 = UD70
Software version of the
Large Option Module
operating system
#17.02 N/A N/A N/A
DPL line number where
trip occured
#17.03
Debugging mode only
Available resources (%) #17.04 0 100 N/A
#17.04 gives an indication of the level of processor resource available by indicating
the percentage of a 128ms period over which the
BACKGROUND task will operate.
ANSI Serial address #17.05 11 99 11
This parameter defines the addresses for serial communications. Range: 11 to 99.
RS485 Mode #17.06 1 12 1
This parameter sets the mode for serial communications. (See below).
RS485 baud rate
(Mode 1, 5, 6 and 7)
#17.07 300 38400 4800
This parameter sets the baud rate: 24 represents 2400... 192 represents 19200, etc.
Maximum is 38400 which is set by a code of 38.
RS485 parameter pointer 1 #17.08 01.00 19.50 0.00
Defines the source parameter for data to be transmitted to a remote Drive when
used in mode 2 and mode 4 communications, and the destination parameter for data
received when using mode 3.
RS485 parameter pointer 2 #17.09 01.00 19.50 0.00
Defines the destination parameter for data received from the remote Drive when
using mode 4 serial communications.
