Control Techniques UD70 User Manual

UD70
Issue code: 70nu2
Features 8-3
8.3 Encoder lines
All position, speed and acceleration parameters within the position
controller use the units of “Encoder lines”. The diagram below shows how
to determine the number of encoder lines for a particular encoder.
A
1 encoder pulse
Encoder lines
A
B
B
Relationship between encoder lines and pulses
