Control Techniques UD70 User Manual

UD70
Issue code: 70nu2
Reference 7-19
Note
Do not over-use the PRINT instruction. It is better to use the
Watch window in the Toolkit in order to monitor
variables.
The
PRINT instruction works in both normal-terminal and
dumb-terminal modes. In normal-terminal mode, the
DPL Toolkit must be used to monitor the print output.
The settings of the RS485 port are fixed at 19200 baud, 8
data bits, 1 stop bit, no parity.
PUTCHAR
Syntax result% = PUTCHAR (character%)
This is a
RS485 port function that writes a character to the RS485
communications port.
If the character could not be written (eg. if the
RS485 port buffer is full), the
function returns 0 0, otherwise it returns 11.
PUTKEY
Syntax result% = PUTKEY (character%)
This is a
RS232 port function that writes a character to the RS232
communications port when operating in dumb-terminal mode only. If the
function fails, it returns 00, otherwise it returns 11.
Example r% = PUTKEY(65) // output 'A' to RS232 port
See also
PRINT instruction.
REINIT
Syntax REINIT
Set up parameters are read by the
UD70 only at the moment AC power is
applied to the Drive or the UD70 is reset. If changes are made to the set-up
parameters by a DPL program, the REINIT instruction can be used to force
the UD70 to re-read them so that changes can take effect.
This instruction will not cause a reset. The program execution continues
from the next instruction as normal.
Example
#17.11 = 25 //Change CLOCK task timebase to 25ms
reinit //reinitializes the UD70to make change take effect
NOTE
REINIT does not read #17.12, POSITION LOOP ENABLE. To
enable or disable the position loop while the Drive is
running, use _Q20%.31 (see Chapter 8).
