Scanning Electron Microscope EM-30PLUS Operating Manual
15
2.2 Explanations on Buttons
2.2.1 E-Gun Power Button
It is used for turning on or off the e-gun.
It is a button for turning on or off the e-gun.
※ Notice: if you turn off the equipment with e-gun on,
it can affect filaments. Be sure to turn off the e-gun
first and then turn off the equipment.
When turned OFF: Gray
When turned ON: Purple
Communications between EM-30PLUS and PC are bad.
1) Confirm the connection state of the USB cable.
2) Change the USB cable to the USB connector of PC.
3) There are communications-related problems in
various boards. ->A/S required
※ When the communications are in a good condition,
the icon doesn’t appear.
