17
9. Connect the Bowden Tube to the Extruder
● Press the collar on the extruder Pneumatic Connector in to the fitting and hold.
● Press the Bowden tube into the connector firmly until it goes no further.
● Release the collar.
● Clip the Connector spacer between the collar and the body of the connector to lock in place.
26
Joint Claw x 2
Bowden Tube

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality ENDER-3 V2 and is the answer not in the manual?

Creality ENDER-3 V2 Specifications

General IconGeneral
Build Volume220 x 220 x 250 mm
Layer Resolution0.1-0.4 mm
Filament Diameter1.75 mm
Nozzle Diameter0.4 mm
Bed LevelingManual
Extruder TypeBowden
Power SupplyMeanWell 350W
Build SurfaceCarborundum Glass
Printing TechnologyFDM (Fused Deposition Modeling)
Max. Nozzle Temperature255°C
Max. Bed Temperature100°C
Machine Dimensions475 x 470 x 620 mm
Machine Weight7.8 kg
ConnectivityUSB, SD Card
Supported MaterialsPLA, ABS, TPU, PETG
Display Screen4.3-inch Color LCD
Print Speed180 mm/s
