3. Cleaning the Nozzle
The Nozzle will slowly accumulate bits of filament on the outside from picking up wisps, the filament curling especially when first bit
is extruded.... over time these will become hard and may stick out and make contact with the extruded filament pulling it along the
build plate.
So heat the nozzle and using a thick cloth, to avoid burning your fingers, make sure the outside is clean.
The inside of the nozzle can also become clogged due to impurities in the filament, the filament deteriorating as it cools.......
If so then this can reduce the filament flow, sometimes irregularly, resulting in thinner lines and debris in the filament.
To clean the nozzle:
● Heat it to at least the filament printing temperature, preferably to 260˚
● Remove the filament completely.
● Carefully clean the outside of the nozzle and gently clean the silicon cover around it.
● Use a correctly sized cleaning needle for the nozzle (the one included is for the standard 0.4mm nozzle)
and insert into the hot nozzle to clean it out and dislodge any blockage.
● Trim the bottom inch off the filament and re insert it.
● Extrude a few centimetres of filament to flush anything out.
If this doesn’t cure the problem repeat the process. If that doesn’t work consider changing the nozzle for a new one.

Creality ENDER-3 V2 Specifications

General

Build Volume	220 x 220 x 250 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Bed Leveling	Manual
Extruder Type	Bowden
Power Supply	MeanWell 350W
Build Surface	Carborundum Glass
Printing Technology	FDM (Fused Deposition Modeling)
Max. Nozzle Temperature	255°C
Max. Bed Temperature	100°C
Machine Dimensions	475 x 470 x 620 mm
Machine Weight	7.8 kg
Connectivity	USB, SD Card
Supported Materials	PLA, ABS, TPU, PETG
Display Screen	4.3-inch Color LCD
Print Speed	180 mm/s
