Creality ENDER-3 V2 - Parts Identification

07
IV. Parts Identification
1
2
3
4
5 6 7 8
Printer Base x 1 Display Assembly x 1 Nozzle Assembly x 1
9
10 11
Z-axis Profile
(left) x 1
Z-axis Profile
(right) x 1
Gantry Profile x 1
12
X-axis Profile x 1
13
Lead Screw x 1
Z-axis Roller Bracket
Assembly
X-axis Tensioner x 1 Z-axis Motor Assembly x 1
Z-axis Limit Switch
Assembly x 1
XE-axis Assembly x 1
