Creality ENDER-3 V2 User Manual

39
Problem
1. Check the wiring to the limit switches, unplug and re-plug the cables into the switch.
2. Try operating the switches by hand, you should be able to feel the switch click as it
closes. If not check the switch for any dirt or obstructions.
3. Check that the metal strip in the limit switch has not been bent too close to the
switch so preventing it from closing.
When I Auto Home it keeps on
trying to move past the end points.
Solutions?
1. Check the displayed Nozzle and bed temperatures, any print will start by heating
the Nozzle and bed and wait until they are up to temperature before proceeding.
1. The USB port only supplies enough power for the motherboard and display.
Check that the mains cable is connected and that the printer is turned on.
When I start a print nothing happens.
I have connected the printer by the
USB cable but the heaters and
movements don’t work

Creality ENDER-3 V2 Specifications

General

Build Volume	220 x 220 x 250 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Bed Leveling	Manual
Extruder Type	Bowden
Power Supply	MeanWell 350W
Build Surface	Carborundum Glass
Printing Technology	FDM (Fused Deposition Modeling)
Max. Nozzle Temperature	255°C
Max. Bed Temperature	100°C
Machine Dimensions	475 x 470 x 620 mm
Machine Weight	7.8 kg
Connectivity	USB, SD Card
Supported Materials	PLA, ABS, TPU, PETG
Display Screen	4.3-inch Color LCD
Print Speed	180 mm/s
