Product Manual – DOC. 8879C DM-NVX-36x(C) Encoders/Decoders • 41
Using SIMPL Windows
Switch subscribed transmitters in Slot-1000: XIO Routing:
1. For each receiver in the daisy chain, clear the existing route by setting the
<VideoOut> analog input join to 0. Using SIMPL Windows, all routes for all
receivers in the chain can be cleared at one time.
2. For each receiver in the daisy chain, select the desired subscribed transmitter
that is to be routed by setting the
<VideoOut> analog input join to the desired
value. Using SIMPL Windows, the desired transmitter can be selected for all
receivers in the chain at one time.
Switching Nonsubscribed Transmitters
To switch nonsubscribed transmitters in a daisy chain configuration, use the web
interface or SIMPL Windows.
Using the Web Interface
To switch nonsubscribed transmitters:
1. Click the Settings tab and then click Stream.
2. In the Advanced section:
a. For each receiver in the daisy chain, disable Auto Initiation and then stop the
stream.
NOTE: Do not proceed to step 2b until Auto Initiation is disabled and the
stream is stopped on all receivers in the chain.
b. For each receiver in the daisy chain:
i. Set a new stream location.
ii. Start the stream.
For additional information, refer to the online help of the web interface.
Using SIMPL Windows
To switch nonsubscribed transmitters, use the top-level programming slot:
1. For each receiver in the daisy chain, trigger the <AutomaticInitiationDisabled>
digital input join to disable automatic initiation, and then trigger the
<Stop>
digital input join to stop the stream.
NOTE: Do not proceed to step 2 until Auto Initiation is disabled and the stream
is stopped on all receivers in the chain.
2. For each receiver in the daisy chain:
a. Set the <StreamLocation> serial input join to a new stream location.
b. Trigger the <Start> digital input join to start the stream.
