Product Manual – DOC. 8879C DM-NVX-36x(C) Encoders/Decoders • 31
Using the Web Interface
Configure Dante or AES67 audio by clicking the Settings tab and then configuring
stream and routing settings:
1. In the Stream section, fill in the appropriate information In the Dante/
Aes-67Name text box by entering the name of the Dante module that will be
used in the Dante Controller.
The default Dante/Aes-67Name text box entry is either of the following:
DM-NVX-363-
xxxxxxyyyyyy
or DM-NVX-363C-
xxxxxxyyyyyy,
where:
•
xxxxxx
equals the last six MAC address characters of the DM NVX device
(for example, 9c099e)
•
yyyyyy
equals the last six MAC address characters of the Dante module
(for example, 80924b)
The name matches the default name in the Dante Controller.
NOTES:
• If the Dante/Aes-67Name text box entry is changed in the web interface, the
new name is automatically added in the Dante Controller but the previous
name is not removed. Changing the
Dante/Aes-67Name text box entry may
disconnect the audio until the route is reestablished in the Dante Controller.
• If the Dante or AES67 name is changed in the Dante Controller rather than
the DM NVX web interface, the name is automatically changed in the
Dante/Aes-67Name text box of the web interface.
Settings Tab - Stream, Dante or AES67 Name
2. In the Routing section:
a. Set Audio Source to Dante/AES-67 Audio.
b. Set Analog Audio Mode to Insert or Extract.
c. Set Dante/AES-67 Transmit Audio Source to the desired audio source for the
Dante or AES67 output.
