Product Manual – DOC. 8879C DM-NVX-36x(C) Encoders/Decoders • 53
Maximum Color Depth and Color Space Mode
Configure the maximum color depth (maximum bit depth supported by the output) and
HDMI color space mode using the web interface or SIMPL Windows.
Using the Web Interface
To configure maximum color depth and color space mode:
1. Click the Settings tab and then click Outputs.
2. In the Outputs table, click the Edit button.
3. In the HDMI Output Setting section:
• Configure maximum color depth in the Max Color Depth drop-down list by
selecting the desired setting.
NOTE: If HDR video is desired at the output, set Max Color Depth to 10-bit
mode.
• Configure color space mode in the Color Space Mode drop-down list by
selecting the desired setting.
NOTE: If HDR video is desired at the output, set Color Space Mode to
Force Y422 or Force Y420.
For additional information, refer to the online help of the web interface.
