Crow Runner Series - System Status and Event Logging; How to Read System Messages; How to Read Trouble Messages; How to Display Events from Memory

8
How to Read System Messages
When viewing the memory events at the keypad by pressing the <MEMORY>/ , the first
thing that is always displayed is the system messages. If the system led turns ON but no other
Zone LED’s are ON at the same time, this means that there are no current system alarms. If a
zone LED and LED’s are ON then this indicates system alarms that have not yet cleared. The
LED’s 1-8 are pre-defined as to what system alarm they display. These system alarm indications
are shown in the table below.
LED 1 Battery Low LED 5 Radio Pendant Battery Low
LED 2 Mains Failure LED 6 Supervised Detector Failure
LED 3 Telephone Line Failure LED 7 Zone Inactivity Timeout
LED 4 Radio Detector Battery Low LED 8 Dialer Kiss-off Failure
Following the display of current system alarms the panel sequences through the 255 historical
memory events starting at the most recent event. The second table shows the alarm events that
can be displayed in memory mode and what indicators are used to show them.
How to Read Trouble Messages
Any failure or abnormal events that may occur are indicated by trouble messages, and the
Trouble indicator is light. Press <MEMORY>/
to read out messages and other events stored
in memory.
How to Display Events from Memory
The system memory stores the last events. Press <MEMORY>/ to display list of events.
Following the display of current system alarms the panel then sequences through the 255
historical memory events starting at the most recent event. The second table shows the alarm
events that can be displayed in memory mode and what indicators are used to show them.
The system displays the last event and you can scrolls to the next event by pressing on the
<MEMORY>/
again.
To exit from memory event display press <ENTER>/
to cancel memory readout.
EVENT TYPE DEVICE INDIC
LED
INDIC
Symbol
STATUS
ACTIVATION Zones 1-16 LED's 1-16 LED's 1-16 On Steady
BYPASS Zones 1-16 Bypass
LED's 1-16
LED's 1-16
On Steady
On Steady
DETECTOR TAMPER
(SHORT CIRCUIT)
Zones 1-8 TAMPER
LED's 1-8
LED's 1-8
Flashing
On Steady
DETECTOR TAMPER
(OPEN CIRCUIT)
Zones 9-16 TAMPER
LED's 9-16
LED's 9-16
Flashing
On Steady
WRONG CODE ALARM Code at Keypad # TAMPER
LED's 1-8
LED's 1-8
On Steady
On Steady
CABINET TAMPER Cabinet or Siren TAMPER
Flashing
KEYPAD TAMPER
SWITCH
Tamper alarm at keypad TAMPER
LED's 1-8
LED's 1-8
On Steady
On Steady
LOW BATTERY Controller Battery BATTERY
Flashing
MAINS FAILURE Controller Mains Supply MAINS
Flashing
FUSE FAILURE F1 or F2 Controller on-board
Fuses
MAINS
LED 1
LED 1
Flashing
RADIO ZONE LOW
BATTERY
Radio Zone 1-16 BATTERY
LED's 1-16
LED's 1-16
Flashing
On Steady
PENDANT LOW BATTERY Radio Key User 1-20 BATTERY
LED's 1-16
LED's 1-16
Flashing
On Steady
