14
Using Local Command Control
If a command control code for outputs is programmed and the output/s are allowed to be locally
controlled from the keypad, then enter the 4 digit code at a keypad then press <ENTER>/
.
The zone display then blanks out and the zone LED’s now indicate the output status.
For example, if output 1 is On, zone 1 LED will turn On. To Turn-Off Output-1, Press the digit
“1” button at the panel keypad, output 1 can be turned off provided it is allowed to be locally
controlled. To leave local command control mode simply press the <ENTER>/
button and
the keypad returns to normal operation. This feature works the same way as the function called
“Directly Controlling an Output”, only difference that it requires a code to access the function.
