3
Audible Signals
When the keypad is used to activate or deactivate the different functions, it emits different
audible beeps. Their meaning is described in the table below.
Table 1 List of Audible Signals
Sound Sequence Description
Short beep Once only A key in the keypad has been pressed.
3 short beeps Once only Operation carried out successfully.
Long beep Once only Illegal operation or wrong key pressed.
Slow beeping Through the Exit or
Entry delay time
Exit or entry delay warning. When arming the system, this
indicates you must exit the protected area. When disarming the
system, it indicates you have entered the protected entry zone.
Indicators (LED Keypad)
There are 30 LED indicators to show the status of the system.
Zone and Status indicators LEDs 1- 16, when all zones sealed <Ready> / light
Partitions indicators LEDs A or B
Armed indicator <ARM> / ,
Memory indicator <Memory> / ,
Bypass indicator <Bypass> /
Program indicator <Program> / ,
CHIME indicator = Aux(0),
Mains indicator <Mains>/
Tamper indicator <Trouble> / ,
Battery indicator <Battery> / ,
Line indicator <Line> / ,
Control indicator <Control> / .
Summary of Functions (LED Keypad)
The system's main functions are listed in table (for LCD symbol the function are the same)
Function Keys Description Notes
Full or
Partition Arm
C O D E
ENTER
Initiates full arm
Full Arm
ARM
Initiates full arm Only if enabled by
installer.
Disarm
during exit
ARM
Disarms the system
during exit delay
Only when slow beeping
is emitted.
Disarm
C O D E
ENTER
Disarms the system Stopping Alarms.
Function Keys Description Notes
Arm Stay
STAY
C O D E
ENTER
Initiates partial alarm
when the user is home
Only if enabled by
installer.
Arm Stay
STAY
Initiates partial alarm
when the user is home
Disarm Stay
C O D E
ENTER
Disarms the system
Disarm Stay
STAY
Disarms the system
Bypass
BYPASS
Zone #
ENTER
Bypasses a zone(s) Repeats the procedure to
