TT250Owner’s andServiceManual
www.CSCMotorcycles.com
21

Therearbrakemastercylinderislocatedundertheseatand
behindthecarburetor.Itisvisiblefromtherightsideofthe
motorcycle,butitiseasiertocheckthebrakefluidlevelif
theleftrearbodypanelisremoved.Theleftrearbody
panelissecuredbya
screwandtwogrommetsnaps.

Therubbergrommetssecuringtherearpanelareshownin
thephotototheright.
Theupperandlowerfluidlevelsoftherearbrakemaster
cylinderareshowninthephotototheright.
FrontBrakePadInspectionandReplacement

Itispossibleto
checkthethicknessonthefrontandrearbrakepadswithoutremovingthecaliperfrom
themotorcycle,butyouhavetogetbelow thebrakecaliperstodoso.Itisbettertoremovethecaliper
tobetterseethepads.

Thefrontbrakecaliperislocatedontheleft
sideofthe
motorcycle.

