ControlCables

TheCSCTT250usesonecontrolcableforthethrottle,andonefortheclutch.

Thethrottlecableshouldbeadjustedsuchthatthereithas2
to5degreesoffreerotationbeforethethrottleisactuated.
Thisaccomplishedthroughuseoftheadjustment
mechanismunderneaththe
righthandlebar.

ClutchcableadjustmentiscoveredintheClutchCablesectionoftheOwner’sandServiceManual.

ClutchandThrottleCableTroubleshooting

Item Symptom Cause VehicleEffect MaintenanceAction
Clutchcable SeeClutchsectionofthisServiceManual
Throttlecable Throttlehasno
freeplay,idle
speedtoohigh,
throttledoesnot
work
Seizedorsticking
throttlecable,
throttlecable
adjustmentincorrect,
throttlecablesnaps
Throttledoesnot
operate,throttlesticks
open
Replaceoradjust
throttlecable

ElectricalSystem

ThissectionoftheOwner’sandServiceManualexplainstheelectri calsystem’smaincomponents,their
locations,theirfunctions,andsomesuggestionsintheunlikelyeventyou’lleverneedtotroubleshoot
thesystem.

TheTT250hasan18‐pole,300‐wattstatorthatputsoutplentyofpower.Many
ridersliketorun
accessories(heatedvests,spotlights,heatedgrips,etc.),andonbikeswithsmallerelectricaloutputs,
youcanrunthebatterydownwhileridingwithalltheaccessoriespoweredup.YourTT250won’thave
thisproblem.

TheTT250hasbuilt‐inaccessoryoutletsalreadywiredintothemain
harness,andtheaccessories
switchislocatedontherighthandlebar(seetheControlssectionoftheOwner’sandServiceManual).

Mostoftheelectricalandelectroniccomponentsonthisbikearelocatedundertheseatandtank,and
behindtheheadlight.

InthissectionoftheOwner’sandService
Manual,wewillremovetheseat,thefueltank,andthe
headlightsoyoucanseeeverything.Thefirstpartofthissectionfocusesonremovingtheseitems;the
secondpartidentifiesvariouselectroniccomponentlocations.
