ξ˜ƒTT250ξ˜ƒOwner’s ξ˜ƒandξ˜ƒServiceξ˜ƒManualξ˜ƒ
www.CSCMotorcycles.comξ˜ƒ
26ξ˜ƒ
ξ˜ƒ
toξ˜ƒremainξ˜ƒopenξ˜ƒwhileξ˜ƒreleasingξ˜ƒtheξ˜ƒbrakeξ˜ƒleverξ˜ƒorξ˜ƒyouξ˜ƒwillξ˜ƒsuckξ˜ƒairξ˜ƒintoξ˜ƒtheξ˜ƒsystem.ξ˜ƒξ˜ƒξ˜ƒRepeatξ˜ƒthisξ˜ƒopen‐
the‐bleed‐port,ξ˜ƒapply‐the‐brake‐lever,ξ˜ƒclose‐the‐bleed‐port,ξ˜ƒadd‐brake‐fluidξ˜ƒprocessξ˜ƒuntilξ˜ƒtheξ˜ƒmasterξ˜ƒ
cylinderξ˜ƒisξ˜ƒfull.ξ˜ƒξ˜ƒξ˜ƒReinstallξ˜ƒtheξ˜ƒbrakeξ˜ƒmasterξ˜ƒcylinderξ˜ƒcover.ξ˜ƒξ˜ƒξ˜ƒForξ˜ƒtheξ˜ƒrearξ˜ƒbrakeξ˜ƒmaster
ξ˜ƒcylinder,ξ˜ƒreinstallξ˜ƒ
theξ˜ƒrearξ˜ƒbrakeξ˜ƒmasterξ˜ƒcylinderξ˜ƒinξ˜ƒitsξ˜ƒproperξ˜ƒlocationξ˜ƒandξ˜ƒreinstallξ˜ƒtheξ˜ƒleftξ˜ƒrearξ˜ƒbodyξ˜ƒpanel.ξ˜ƒ
ξ˜ƒ
Priorξ˜ƒtoξ˜ƒtakingξ˜ƒtheξ˜ƒmotorcycleξ˜ƒonξ˜ƒtheξ˜ƒstreet,ξ˜ƒoperateξ˜ƒitξ˜ƒslowlyξ˜ƒandξ˜ƒapplyξ˜ƒtheξ˜ƒbrakesξ˜ƒseveralξ˜ƒtimes.ξ˜ƒξ˜ƒξ˜ƒ
ξ˜ƒ
Brakeξ˜ƒTroubleshootingξ˜ƒ
ξ˜ƒ
Brakeξ˜ƒtroubleshootingξ˜ƒproceduresξ˜ƒareξ˜ƒsummarizedξ˜ƒbelow.ξ˜ƒ
ξ˜ƒ
Frontξ˜ƒandξ˜ƒRearξ˜ƒBrakeξ˜ƒTroubleshootingξ˜ƒandξ˜ƒMaintenanceξ˜ƒ
Itemξ˜ƒ Symptomξ˜ƒξ˜ƒ Cause Vehicleξ˜ƒEffectξ˜ƒ Maintenanceξ˜ƒAction
Brakeξ˜ƒpadξ˜ƒ Reducedξ˜ƒbrakingξ˜ƒ
forceξ˜ƒ
Wornξ˜ƒbrakeξ˜ƒpad(s) Longerξ˜ƒstoppingξ˜ƒ
distanceξ˜ƒ
Replaceξ˜ƒbrakeξ˜ƒpad
Airξ˜ƒinξ˜ƒbrakeξ˜ƒlinesξ˜ƒ Reducedξ˜ƒbrakingξ˜ƒ
forceξ˜ƒ
Airξ˜ƒintrusionξ˜ƒintoξ˜ƒ
brakeξ˜ƒlineξ˜ƒ
Longerξ˜ƒstoppingξ˜ƒ
distanceξ˜ƒ
Bleedξ˜ƒbrakes
Pulsatingξ˜ƒbrakesξ˜ƒ Pulsatingξ˜ƒbrakeξ˜ƒlever Warpedξ˜ƒrotorξ˜ƒdisk Pulsations;ξ˜ƒlongerξ˜ƒ
stoppingξ˜ƒdistanceξ˜ƒ
Measureξ˜ƒdiskξ˜ƒ
runout,ξ˜ƒreplaceξ˜ƒdiskξ˜ƒ
rotorξ˜ƒ
ξ˜ƒ
Powerξ˜ƒTransmissionξ˜ƒ
ξ˜ƒξ˜ƒ
Theξ˜ƒTT250ξ˜ƒusesξ˜ƒaξ˜ƒmanually‐operatedξ˜ƒwetξ˜ƒclutchξ˜ƒandξ˜ƒaξ˜ƒchainξ˜ƒdriveξ˜ƒsystem.ξ˜ƒ
ξ˜ƒ
Chainξ˜ƒDriveξ˜ƒSystemξ˜ƒ
ξ˜ƒ
Thisξ˜ƒsystemξ˜ƒconsistsξ˜ƒofξ˜ƒtheξ˜ƒclutch,ξ˜ƒtheξ˜ƒcountershaftξ˜ƒsprocket,ξ˜ƒtheξ˜ƒrearξ˜ƒsprocket,ξ˜ƒtheξ˜ƒrearξ˜ƒwheel,ξ˜ƒandξ˜ƒtheξ˜ƒ
driveξ˜ƒchain.ξ˜ƒ
ξ˜ƒ
Chainξ˜ƒLubricationξ˜ƒ
ξ˜ƒ
Theξ˜ƒdriveξ˜ƒchainξ˜ƒshouldξ˜ƒbeξ˜ƒlubricatedξ˜ƒapproximatelyξ˜ƒeveryξ˜ƒ500ξ˜ƒmilesξ˜ƒ
orξ˜ƒmoreξ˜ƒoftenξ˜ƒifξ˜ƒridingξ˜ƒinξ˜ƒrainyξ˜ƒorξ˜ƒ
dustyξ˜ƒconditions.ξ˜ƒξ˜ƒξ˜ƒUseξ˜ƒonlyξ˜ƒaξ˜ƒqualityξ˜ƒwax‐basedξ˜ƒorξ˜ƒpetroleumξ˜ƒbasedξ˜ƒmotorcycleξ˜ƒchainξ˜ƒlubricant.ξ˜ƒξ˜ƒRideξ˜ƒ
theξ˜ƒmotorcycleξ˜ƒforξ˜ƒatξ˜ƒleastξ˜ƒ15ξ˜ƒminutesξ˜ƒtoξ˜ƒwarmξ˜ƒtheξ˜ƒchain,ξ˜ƒand ξ˜ƒapplyξ˜ƒtheξ˜ƒlubricantξ˜ƒimmediatelyξ˜ƒafterξ˜ƒ
stopping.ξ˜ƒξ˜ƒWarning!ξ˜ƒTakeξ˜ƒcareξ˜ƒnotξ˜ƒtoξ˜ƒsprayξ˜ƒlubricantξ˜ƒontoξ˜ƒtheξ˜ƒtireξ˜ƒorξ˜ƒtheξ˜ƒrearξ˜ƒbrake.ξ˜ƒξ˜ƒξ˜ƒDoξ˜ƒnotξ˜ƒuseξ˜ƒtheξ˜ƒ
motorcycleξ˜ƒforξ˜ƒtheξ˜ƒnextξ˜ƒ15ξ˜ƒminutesξ˜ƒtoξ˜ƒallowξ˜ƒtheξ˜ƒlubricantξ˜ƒtoξ˜ƒseepξ˜ƒintoξ˜ƒtheξ˜ƒchain.ξ˜ƒ
ξ˜ƒ
Chainξ˜ƒAdjustmentξ˜ƒ
ξ˜ƒ
Thisξ˜ƒsectionξ˜ƒofξ˜ƒtheξ˜ƒOwner’sξ˜ƒandξ˜ƒServiceξ˜ƒManualξ˜ƒaddressesξ˜ƒadjustingξ˜ƒtheξ˜ƒTT250ξ˜ƒmotorcycl e’sξ˜ƒchainξ˜ƒ
andξ˜ƒ
aligningξ˜ƒtheξ˜ƒrearξ˜ƒwheel.ξ˜ƒξ˜ƒYouξ˜ƒwillξ˜ƒneedξ˜ƒ13mm,ξ˜ƒ18mm,ξ˜ƒandξ˜ƒ19mmξ˜ƒwrenches,ξ˜ƒandξ˜ƒaξ˜ƒscrewdriverξ˜ƒforξ˜ƒthisξ˜ƒ
maintenanceξ˜ƒactivity.ξ˜ƒ
ξ˜ƒ
Youξ˜ƒdon’tξ˜ƒhaveξ˜ƒtoξ˜ƒgetξ˜ƒtheξ˜ƒrearξ˜ƒwheelξ˜ƒoffξ˜ƒtheξ˜ƒgroundξ˜ƒtoξ˜ƒadjustξ˜ƒtheξ˜ƒTT250’sξ˜ƒchain.ξ˜ƒξ˜ƒξ˜ƒξ˜ƒ
ξ˜ƒ
