Pushthecaliperpistonsallthewayintothecaliper.

Assemblyisthereverseofdisassembly.Installnewfrontpads,installthetwo5mmAllenpins,place
thecaliperovertherotor,andinstallthetwocalipermountingbolts.The5mmAllenpinsshouldbe
torquedto3to5
ft‐lbs.Thecalipermountingboltsshouldbetorquedto15to18ft‐lbs.

RearBrakePadInspectionandReplacement

Therearbrakecaliperislocatedontherightsideofthe
swingarm.

Loosentherearbrakecaliper’stwo5mmAllenpi ns.

Removethecaliper’stwo8mmmounting
boltsandthen
removethecaliperfromtheswingarm.Youshouldnot
removethehydraulicbrakelineorloosenit.

