Theforksealandbushingatthebottomoftheforkupper
areshownhere.Theredarrowontherightpointstothe
forkseal.Theredarrowontheleftpointstothebushing.
Thereisanironwasherbetweentheforksealandbushing.
Gentlyprythefork
sealoutofthefork.Youcansimilarly
removetheforkbushingwithapick.

Caution!Takecarenottomartheforkupperwhen
performingthisoperation.

Afterremovingtheforkseal,thedustseal,andthebushing,
examinethesepartscarefullyforanycuts,tears,or
degradation.Replacethedefectivepart(s).CSCstocksthese
parts;pleasecallusat9094450900if
youneedreplacement
sealsorbushing.
Assemblyisthereverseofdisassembly.

SwingarmandRearSuspension

ThissectionoftheOwner’sandServiceManualaddressesswingarmandrearsuspension
maintenance.
Thefirststepistosafelyelevatetherearendofthe
motorcycle.Weuseamotorcyclejack;anysuitable
lift
methodwillwork.
Removetherearwheel.Rearwheelremovaliscoveredin
theTT250WheelRemovalsectionoftheOwner’sand
ServiceManu al.
